UNIQUE ID 1398: M4A1 (76) SHERMAN TANK

Lewis Army Museum, Joint Base Lewis-McChord, USA

(Location: LTC Herbert M. Mills Memorial)


Powered By Subgurim(http://googlemaps.subgurim.net).Google Maps ASP.NET
Powered By Subgurim(http://googlemaps.subgurim.net).Google Maps ASP.NET

MAP CONTROLS: Use slider or mousewheel to zoom, and hold down left mouse button to drag.
KEY: Location markers are coloured from Green meaning exact to Red meaning gone or unknown (details here)

Sample Photo from Tank with UniqueID 1398


Unique ID: 1398
Added to Database: 14 November 2010
Last Edited: 27 December 2010
Type (ID): M4A1 (76) Sherman (1350)
Model (ID): M4A1 (76) (1350)
Location Category (ID): Lewis Army Museum (97100)
Location (ID): LTC Herbert M. Mills Memorial (97112)
Serial Number: 52499: Retrieved by museum staff from the data plate (source: K. Laughlin).
Turret: 1885 (“2 1885” cast into sides, “1885” cast into roof).
Transmission cover: 0818 (“[G] E8543 C 0818 LO-” cast into underside).
Registration:
Name:
Other Identification: Cavalry Branch guidon painted on turret sides: “1” in top half, “8” in bottom half (previously “8” / “2”, before that “14” / “2”). White stars painted on hull sides and glacis.
Collection Reference:
Links:
References:
Associated Tanks:

Location History:
(see map)

1: Pressed Steel Car Company, Hegewisch, Chicago, Illinois, USA (Manufacturer)
2: Germany (Dates unknown)
3: Lewis Army Museum, Joint Base Lewis-McChord, Pierce County, Washington, USA (Current location)


Text in original Preserved American Tanks publication:

[No entry]

Text in Preserved American Tanks Update:

[No entry]

Text in original Preserved Tanks In USA publication:

According to museum staff both Fort Lewis Shermans came from Germany (source: N. Baumgardner). In 2000 they had been on display side by side next to an armour unit headquarters (source: K. Laughlin).
One of the hatches on this M4A1 is open and its interior appears to be largely complete; it retains its radial engine (source: C. Sherman). This markings on its transmission cover indicate that the cover was manufactured by American Steel Foundries, Granite Works (“[G]”), Illinois; it is a late production version (“E8543”, source: P.-O. Buan) with serial number 0818.


Images - Photographs and NavPix (click to expand or browse)

October 2010

Right view
1: Right view

Taken: October 2010
Contributor: C. Sherman
Photo ID: 4053
Added: 25 December 2010
Filename: 10201000...
Views: 204
Select/Has Priority: 21/0




Rear left view
2: Rear left view

Taken: October 2010
Contributor: C. Sherman
Photo ID: 4054
Added: 25 December 2010
Filename: 10201008...
Views: 637
Select/Has Priority: 21/0




Casting mark on transmission cover
3: Casting mark on transmission cover

Taken: October 2010
Contributor: C. Sherman
Photo ID: 4055
Added: 25 December 2010
Filename: 10201000...
Views: 162
Select/Has Priority: 21/0




June 2006

Right view
4: Right view

Taken: June 2006
Contributor: C. Sherman
Photo ID: 3966
Added: 14 November 2010
Filename: 0001w_m4...
Views: 198
Select/Has Priority: 21/0








September 2004

Right view
5: Right view

Taken: 19 September 2004
Contributor: J. Smigh
Photo ID: 4017
Added: 22 November 2010
Filename: Dig_M4A1...
Views: 159
Select/Has Priority: 21/0
