KV-1 Tank



Powered By Subgurim(http://googlemaps.subgurim.net).Google Maps ASP.NET

MAP CONTROLS: Use slider or mousewheel to zoom, and hold down left mouse button to drag.
KEY: Location markers are coloured from Green meaning exact to Red meaning gone or unknown (details here)

The KV-1 (Klimenti-Voroshilov-1) was developed under the direction of Zh Ya Kotin at the SKB-2 design bureau at the Kirovsky Tank Plant in Leningrad. It was accepted for series production for the Russian Army in December 1939 and was produced in several versions with constant upgrading of the armament, armour and mechanical components. Relatively few KV-1’s survived the war. The Russian Army did not readily distinguish production models of the KV-1, so the year and type provided here are generally accepted descriptions, not Russian definitions. The KV-1 “A”, “B” and “C” references are Western designations, base on wartime German intelligence reports. In total 4800 KV tanks of all types were produced.

Model Id:2770
Manufacture:


1) Museé Des Blindés, Saumur, France

Number of Photos: 1
Sample Photo from Album Number 966

Click here or on the image for this tank's profile page

Unique ID: 966
Serial Number:
Registration:
Name:
Other Identification:

Model 1941 (Welded Turret)

The early M-1940 and M-1941’s were provided with a welded steel turret of which there are several types, differing in dimensions and detail, particularly with regard to the rear turret bustle overhang. Late in 1941 the KV-1 received a cast turret.

Model 1941 (Cast Turret)

In November 1941, the LKZ plant was evacuated to Chelyabisk and by October 1941 was producing a modifid tank with a cast turret, 76.2mm ZiS-5 gun and a simplified hull design. The new cast turret which was easier to produce and provided heavier, more consistent armour protection than the original welded design.

Model Id:2774
Manufacture:Chelyabinskiy Traktornyy Zavod (ChTZ), Chelyabinsk, Chelyabinsk Oblast, Ekaterinburg and Surrounding Regions, Russia (Sole manufacturer)


2) The Tank Museum - Public Areas, Bovington, Britain

Number of Photos: 12
Sample Photo from Album Number 1937

Click here or on the image for this tank's profile page

Unique ID: 1937
Serial Number: 11306: “11306” engraved into the glacis.
Registration:
Name:
Other Identification: “716” and a patriotic slogan painted on turret sides. Painted overall in a whitewash (previously overall green).

3) U.S. Army Ordnance Museum, Aberdeen Proving Ground, USA

Number of Photos: 3
Sample Photo from Album Number 677

Click here or on the image for this tank's profile page

Unique ID: 677
Serial Number:
Registration:
Name:
Other Identification:

Model 1941 E (S Ekranami)

The KV-1 M-1941 E (Ekranirovanniy bronney - added armour) was developed as a result of experiences on the Finnish Front where the relatively light side armour of the original KV welded turret was found to be vulnerable to well placed anti-tank fire. The turret was consequentlyup-armoured using 25-35mmarmour plates secured to the turret with large bolts. The resulting gap was normally filled with sheet steel. On some tanks plates were also mounted on the hull above and below the track guards. The additional armour was an effective stopgap measure pending the introduction of the new cast turret design. From July-September 1941, some 25% of all KV's were so modified. New roadwheels were also simultaneously used to reduce weight.

Model 1942

The Model 1942 has a cast turret of a later, up-armoured type, most easily distinguished by the armoured ring around the rear turret machine gun. Some of these later tanks also featured the sloped rear deck of the KV-1S, which slightly reduced overall weight.

Model Id:2778
Manufacture:Chelyabinskiy Traktornyy Zavod (ChTZ), Chelyabinsk, Chelyabinsk Oblast, Ekaterinburg and Surrounding Regions, Russia (Sole manufacturer)


4) Fort IX Czerniaków, Mokotów, Poland

Number of Photos: 0
Sample Photo from Album Number 2226

Click here or on the image for this tank's profile page

Unique ID: 2226
Serial Number:
Registration:
Name:
Other Identification:
